19
C20
Fig. 7c
USE ONLY A SCREW IN POSITION “A”.
A
11.7
72
60
D>5
10.5
35.5
30
WING
FRAME
MIN. 33
50
50
B
1
VER.0.0
REV.09.13
INSTALLATION AND USE ISTRUCTIONS
Dimensions in mm
DOME OPENING
THE RELEASE SIDE INDICATOR (REF. 1) IN THIS ASSEMBLY TYPE HAS TO BE ON
THE LEFT.
240
40
360 43
300
400
48°
55°
"B" MOTOR OVERALL
DIMENSIONS (mm)
STROKE (mm)
MIN. WINDOW
GAP (mm)
OPENING
ANGLE
INSTALLATION -5
