Torit Downflo SDF-2 - Figure 16 - Prewired with Checker Board on Unit; Figure 17 - Unwired with Checker Board on Unit

Donaldson Company, Inc. © 1995
21
Figure 16
Prewired with Checker Board on Unit
Power Cord
To Low Pressure
To High Pressure
Vinyl Tubing
Vinyl Tubing
Safety Filters
Checker
board
Door Shown in
Open Position
Figure 17
Unwired with Checker Board on Unit
Safety Filters
Vinyl Tubing
Access for Wiring
to Motor
Mounting Panel for
Motor Starter
Access for
Power Cord
To Low Pressure
To High Pressure
Wiring to
Solenoid Valves
Wiring to
Temperature Sensors
Door Shown in
Open Position
Checker board
