Torit Downflo SDF-2 - Figure 30 Magnehelic Gage; Figure 31 - Remote-Mounted Magnehelic Gage

32
Donaldson Company, Inc. © 1995
Figure 31
Remote-Mounted Magnehelic Gage
Magnehelic
Gage
Screw Self-Drilling
Mounting Panel
Figure 30
Magnehelic Gage
Plastic Tubing
Tubing Male Adapters
1/8" NPT
Low Pressure Port (Ref)
High Pressure Port (Ref)
Dirty Air Plenum
Clean Air Plenum
Magnehelic
Gage
