2.6.5 Torit
∆∆
∆∆
∆P Control (See Figure 32
Torit
∆∆
∆∆
∆P Control Wiring Diagram &
Figure 33 Printed Circuit Board )
CAUTION
• All electrical work is to be done by a
qualified electrician according to the
national and local electrical codes that
apply.
• All electrical power must be shut off
during installation.
• Do not apply in hazardous (classified)
atmospheres.
NOTE
• Do not mount controls in a high
vibration area without shock mounts.
• Do not mount controls in corrosive
atmospheres without an appropriate
enclosure.
• Do not operate with the enclosure open.
Figure 32
∆P Control Display
