28
Donaldson Company, Inc. © 1995
Figure 28
Remote Checker Board Assembly
Control Panel Label
Remote Checker board
Assembly Kit
Low Pressure (Clean Air)
Control Box
Terminal Strip
Flat Cable
High Pressure (Dirty Air)
High and Low Pressure Fittings
Control Box
Cover of Control Box
