Torit Downflo SDF-2 - Figure 34 Photohelic Gage; Figure 35 - Remote-Mounted Photohelic Gage

36
Donaldson Company, Inc. © 1995
Figure 35
Remote-Mounted Photohelic Gage
Screw Self-Drilling
Photohelic Gage
Mounting Bracket
Figure 34
Photohelic Gage
Tubing Male
Adapters 1/8" NPT
Low Pressure Port (Ref)
High Pressure Port (Ref)
Plastic Tubing
Photohelic
Gage
Dirty Air Plenum
Clean Air Plenum
