Toro 2024 - System Setup Procedures; Deploying the Zap-Alert System

Figure40
1.Screw2.Cover
4.Lowerthepedestriansafetybarandsecureitinplace
(Figure41).
Figure41
1.Pedestriansafetybar(loweredpositionshown)
5.Pushdownontherearplatformlatchsecuringthe
operatorplatform,andswingitouttothedesired
position,ensuringthatitlocksinplace(Figure42).
Note:Theoperatorplatformhas4positions:travel
(swungallthewayintothemachine),full-out,and2
intermediatepositions.
Figure42
1.Rearplatformlatch
DeployingtheZap-AlertSystem
TheZap-Alertsystemisanelectricstrikesensingdeviceon
themachinethattriggersastrobelightandaudiblealarmin
theeventthatthedrillbit,reamer,orstakebreaksintoan
energizedpowerline.Intheeventofanelectricstrike,the
machinewillbecomeenergized,settingoffthealarm.The
operator’splatformiselectricallyisolatedfromtherestof
themachinetoprotectyou.
