Toro 30411 - 1 Installing the Seat, Seat Belt, and Manual Tube; Setup

Setup
Loose Parts
Use the chart below to verify that all parts have been shipped.
Step
Description
Qty.
Use
Seat kit (obtain separately)
1
Seat suspension kit (obtain
separately)
1
Manual tube
1
R-clamp
2
Seat belt
1
Bolt
2
1
Lock washer
2
Install the seat, seat belt, and
manual tube.
2
No parts required
–
Grease the machine.
Operator’s Manual
1
Engine Operator’s Manual
1
Parts Catalog
1
Operator Training DVD
1
Pre-delivery Inspection Sheet
1
3
CE certicate
1
Read the manuals and watch the
DVD before operating the machine.
Use the remaining parts for the
installation of attachments.
Note: Deter mine the left and right sides of the
mac hine from the nor mal operating position.
Step
1
Installing the Seat, Seat
Belt, and Manual Tube
Parts needed for this step:
1
Seat kit (obtain separately)
1
Seat suspension kit (obtain separately)
1
Manual tube
2
R-clamp
1
Seat belt
2
Bolt
2
Lock washer
Procedure
T he mac hine is shipped without the seat assembly .
T he Delux e Seat, Model No . 30398, and Seat
Suspension Kit, Model No . 30396 or the Premium
Seat, Model No . 30622, and Premium Suspension
Kit, Model No . 30621, m ust be purc hased and
installed.
1. Mount the man ual tube to the seat suspension
with the 2 R-clamps included in loose par ts .
2. Install the seat belt to eac h side of the seat with
a bolt and loc k w asher , supplied in loose par ts .
Important: Mak e sur e that the seat
s witch wir e is connected to the seat s witch
connector on the har ness.
3. Slide the seat completely forw ard and bac kw ard
to ensure proper operation and that seat switc h
wires and connectors are not pinc hed or do no
contact any mo ving par ts .
14
