Toro 30411 User Manual

ProductOverview
Controls
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
CAUTION
Thismachineproducessoundlevelsinexcessof85
dBAattheoperatorsearandcancausehearingloss
throughextendedperiodsofexposure.
Wearhearingprotectionwhenoperatingthis
machine.
TractionPedal
Tostop,reduceyourfootpressureonthetractionpedal
andallowittoreturntothecenterposition(Figure2).
Figure2
1.Brakepedals6.Fuelgauge
2.Pedallockinglatch
7.Hazardlightswitch(GM
4100only)
3.Spaceforoptional
accessory
8.Tiltsteeringlever
4.Spaceforoptional
accessory
9.Tractionpedal
5.Parkingbrakelatch
BrakePedals
TwofootpedalsFigure2operateindividualwheelbrakes
forturningassistance,parking,andtoaidinobtaining
bettersidehilltraction.Alatchconnectsthepedalsfor
parkingbrakeoperationandtransport.
PedalLockingLatch
ThepedallockinglatchFigure2connectsthepedals
togethertoengagetheparkingbrake.
TiltSteeringLever
PresstheleverFigure2downtotiltthesteeringwheel
tothedesiredposition.Thenreleasethelevertolock
theadjustment.
ParkingBrakeLatch
Aknobontheleftsideoftheconsoleactuatesthe
parkingbrakelock(Figure2).Toengagetheparking
brake,connectthepedalswiththelockinglatch,push
downonbothpedals,andpulltheparkingbrakelatch
out.Toreleasetheparkingbrake,pressbothpedalsuntil
theparkingbrakelatchretracts.
FuelGauge
Thefuelgauge(Figure2)indicatestheleveloffuelin
thetank.
HazardLightSwitch(GM4100only)
Pressthehazardlightswitch(Figure2)toactivatethe
hazardlights.
SpeedLimiter
Ifdesired,thescrewcanbeadjusted(Figure3)tolimit
theamountthetractionpedalcanbedepressedinthe
forwarddirectiontolimitthemowingspeed.
Figure3
1.Speedlimiter
Important:Wheninthemowposition,thespeed
limiterscrewmuststopthetractionpedalbeforethe
15
