Toro 30484 - Product Overview; Controls

114-3424
1.Tractioncontrol
3.Slow
5.Reverse
2.Fast4.Neutral
6.DisengagethePTO(PowerT akeOff)
ProductOverview
g014654
1
2
3
4
5
6
7
Figure4
1.Sidedischargechute
5.Parkingbrake
2.Engine6.Mowerdeck
3.Gastank
7.Frontcasterwheel
4.Controls
Controls
Becomefamiliarwithallthecontrols(Figure5)before
youstarttheengineandoperatethemachine.
Figure5
1.Ignitionswitch
6.Choke
2.Leftmotioncontrollever7.Neutrallockpositionfor
rightmotioncontrollever
3.Throttlecontrol8.Rightmotioncontrollever
4.Hourmeter
9.bladecontrolswitch(PTO)
5.Fueltank
10.Operatormanualtube
HourMeter
Thehourmeterrecordsthenumberofhourstheengine
hasoperated.Itoperateswhentheengineisrunning.
Usethesetimesforschedulingregularmaintenance
(
Figure6).
SafetyInterlockIndicators
Therearesymbolsonthehourmeterandindicatewith
ablacktrianglethattheinterlockcomponentisinthe
correctposition(Figure6).
BatteryIndicatorLight
WhentheignitionkeyisinitiallyturnedtotheOn
position,thebatteryvoltagewillbedisplayedinthearea
wherethehoursarenormallydisplayed.
Thebatterylightturnsonwhentheignitionisturned
onandwhenthechargeisbelowthecorrectoperating
level(
Figure6).
11
