Toro 30484 - Using the MID-Size Weight

UsingtheMid-SizeWeight
Weightsareinstalledoncertainmowerstoimprove
balanceandimproveperformance.Theweightscanbe
movedorremovedtocreateoptimizedperformance
underdifferentmowingconditionsandforoperator
preference(Figure22orFigure23).
Thefollowingtableindicatesthepositionoftheweight
asinstalledatthefactory.
MowerDeckSizeNumberofweights
install
Positionofthe
weight
36inches1Front
40inches1Front
48inches
nonenone
52inches1Rear
•Anyrearweightmustberemovedwhena
Tru–Track
®
Sulkyisinstalled.
•WhenaTru–Track
®
Sulkyisinstalledfrontweights
areneeded.ContactanAuthorizedServiceDealer
forthecorrectquantityofweightsandplacement.
WARNING
Thefrontendofthemachinecanrapidlyriseup
whenthemowerisremoved.Thiscouldcause
seriousinjurytoyouorbystanders.
Supporttherearofthemachinewhenremoving
themowerfromthecarrierframe.
Figure22
Installingthefrontweight.
1.Bolt3.Weight
2.Washer4.Nut
Figure23
Installingtherearweight.
1.Nut3.Washer
2.Weight4.Bolt
22
