Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Warningdecal1
CEdecal
1
1
Production-yeardecal1
Replacethedecals(CEmachinesonly).
Hood-latchbracket1
Rivet2
Washer1
Screw(1/4x2inches)
1
2
Locknut(1/4inch)
1
Installthehoodlatch(CEmachines
only).
3
Nopartsrequired
–
Adjusttherollerscraper(optional).
4
Nopartsrequired
–
Installthemulchingbafe(optional).
5
Nopartsrequired
–
Preparethemachine.
MediaandAdditionalParts
Description
Qty.
Use
Operator'sManual
1
Reviewbeforeoperatingthemachine.
Engineowner’smanual1
Refertothemanualforadditionalmaintenanceinformation.
DeclarationofConformity
1
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
InstallingtheDecals(CE
MachinesOnly)
Partsneededforthisprocedure:
1Warningdecal
1
CEdecal
1Production-yeardecal
Procedure
OnmachinesrequiringCEcompliance,replacethe
warningdecal,CEdecal,andtheproduction-year
decal(Figure3).
g279018
Figure3
1.Warningdecal3.Production-yeardecal
2.CEdecal
