Toro 30873TE - Adjusting the Roller Scraper; Installing the Mulching Baffle

g012631
Figure7
1.Bolt
3.Armofhood-latchbracket
2.Nut
3
AdjustingtheRoller
Scraper
Optional
NoPartsRequired
Procedure
Theoptionalrearrollerscraperfunctionsbestwhen
thereisanevengapof0.5to1mm(0.02to0.04inch)
betweenthescraperandtheroller.
1.Loosenthegreasettingandthemounting
screw(Figure8).
g031578
Figure8
1.Rollerscraper
3.Greasetting
2.Mountingscrew
2.Slidethescraperupordownuntilyouobtaina
gapof0.5to1mm(0.02to0.04inch)between
therodandtheroller.
3.Tightenthegreasettingandscrewto41N∙m
(30ft-lb)inanalternatingsequence.
4
InstallingtheMulching
Bafe
Optional
NoPartsRequired
Procedure
ContactyourauthorizedT orodistributorforthecorrect
mulchingbafe.
1.Thoroughlycleandebrisfromthemountingholes
ontherearwallandleftwallofthechamber.
2.Installthemulchingbafeintherearopening
andsecureitwith5ange-headbolts(Figure9).
g031579
Figure9
1.Mulchingbafe
2.Flange-headbolt
3.Verifythatthemulchingbafedoesnotinterfere
withthetipofthebladeanddoesnotprotrude
insidethesurfaceoftherearchamberwall.
DANGER
Usingthehigh-liftbladewiththe
mulchingbafecouldcausetheblade
tobreak,resultinginpersonalinjuryor
death.
Donotusethehigh-liftbladewiththe
bafe.
14
