Toro 30873TE - Checking the Interlock Switches; Checking the Blade-Stopping Time

g011344
Figure21
1.Height-of-cutbracket3.Spacer
2.Height-of-cutplate
4.Whilesupportingthechamber,removethe
spacer(Figure21).
5.Movethechambertothedesiredheightof
cutandinstallaspacerintothedesignated
height-of-cutholeandslot(Figure22).
g201855
Figure22
6.Positionthetappedplatein-linewiththespacer.
7.Installtheboltnger-tight.
8.Repeatsteps4through7foreachside
adjustment.
9.Torqueall3boltsto41N∙m(30ft-lb).Always
tightenthefrontboltrst.
Note:Adjustmentsofmorethan3.8cm(1-1/2
inches)mayrequiretemporaryassemblytoan
intermediateheighttopreventbinding(e.g.,
changingfrom3.1to7cm(1-1/4to2-3/4inches)
heightofcut).
CheckingtheInterlock
Switches
ServiceInterval:Beforeeachuseordaily
CAUTION
Ifsafetyinterlockswitchesaredisconnected
ordamaged,themachinecouldoperate
unexpectedly,causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthemachine.
Theinterlockswitchesaredesignedtoshutoffthe
machinewhenyourisefromtheseatwhenthe
tractionpedalispressed.However,youmayrisefrom
theseatwhiletheengineisrunningandthetraction
pedalisintheNEUTRALposition.Althoughtheengine
continuestorunwhenyoudisengagethePTOswitch
andreleasethetractionpedal,shutofftheengine
beforerisingfromtheseat.
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,lowerthecuttingunits,andturn
thekeytotheOFFposition.
2.Pressthetractionpedalandturnthekeytothe
ONposition.
Note:Iftheenginecranks,thereisa
malfunctionintheinterlocksystem.Correctthis
malfunctionbeforeoperatingthemachine.
3.TurnthekeytotheONposition,risefromthe
seat,andmovethePTOswitchtoON.
Note:ThePTOshouldnotengage.Ifthe
PTOengages,thereisamalfunctioninthe
interlocksystem.Correctthismalfunctionbefore
operatingthemachine.
4.Engagetheparkingbrake,turnthekeytothe
ONpositionandmovethetractionpedaloutof
theNEUTRALposition.
Note:TheInfoCenterdisplays"tractiondenied"
andthemachineshouldnotmove.Ifthe
machinedoesmove,thereisamalfunctionin
theinterlocksystem.Correctthismalfunction
beforeoperatingthemachine.
Checkingthe
Blade-StoppingTime
ServiceInterval:Beforeeachuseordaily
Note:Lowerthecuttingunitsontoacleansectionof
turforhardsurfacetoavoidthrowingdustanddebris.
Toverifythisstoppingtime,havesomeonestandback
fromthecuttingunitsatleast6m(20ft)andwatchthe
bladeson1ofthecuttingunits.DisengagethePTO
andrecordthetimeittakesforthebladestocometo
acompletestop.Ifthistimeisgreaterthan7seconds,
28
