Toro 30873TE - Installing the Hood Latch

2
InstallingtheHoodLatch
CEMachinesOnly
Partsneededforthisprocedure:
1Hood-latchbracket
2Rivet
1Washer
1
Screw(1/4x2inches)
1
Locknut(1/4inch)
Procedure
1.Unhookthehoodlatchfromthehood-latch
bracket.
2.Removethe2rivetssecuringthehood-latch
brackettothehood(Figure4).
g012628
Figure4
1.Hood-latchbracket2.Rivets
3.Removethehood-latchbracketfromthehood.
4.Whilealigningthemountingholes,positionthe
CElockbracketandthehood-latchbracketonto
thehood(Figure5).
Note:Thelockbracketmustbeagainstthe
hood.Donotremovetheboltandnutfromthe
lock-bracketarm.
g012629
Figure5
1.CElockbracket
2.Boltandnut
5.Alignthewasherswiththeholesontheinsideof
thehood.
6.Rivetthebracketsandthewasherstothehood
(Figure5).
7.Hookthelatchontothehood-latchbracket
(Figure6).
g012630
Figure6
1.Hoodlatch
8.Installtheboltintotheotherarmofthe
hood-latchbrackettolockthelatchinposition
(Figure7).Tightentheboltbutdonottighten
thenut.
13
