ProductOverview
Controls
g009979
Figure10
1.Brakepedal4.Tractionpedal
2.Pedal-lockinglatch5.Tilt-steeringpedal
3.Parking-brakepedal
TractionPedal
Thetractionpedal(Figure10)controlsforwardand
reverseoperation.Pressthetopofthepedaltomove
forwardandthebottomtomovebackward.
Tostopthemachine,use1ofthefollowing
procedures:
•Reduceyourfootpressureonthetractionpedal
andallowittoreturntothecenterposition.The
machinedynamicallybrakestoasmoothstop.
•Taporholdthereversepedalbriey.Thisstops
themachinefasterthandynamicbraking.
Note:Inemergencybrakingsituations,pressthe
servicebrakepedalsinadditiontousingthereverse
pedalasstatedabove.Thisisthequickestwayto
stopthemachine.
BrakePedals
Thereare2footpedalsthatoperateindividualwheel
brakesforturningassistance,parking,andtoaidin
betterside-hilltraction.Alatchconnectsthepedals
forparking-brakeoperationandtransport(Figure10).
Pedal-LockingLatch
Thepedal-lockinglatchconnectsthepedalstogether
toengagetheparkingbrake(Figure10).
Parking-BrakePedal
Toengagetheparkingbrake,(Figure10)connectthe
pedalstogetherwiththepedal-lockinglatchandpush
downontherightbrakepedalwhileengagingthetoe
pedal.Toreleasetheparkingbrake,press1ofthe
brakepedalsuntiltheparkingbrakelatchretracts.
Tilt-SteeringPedal
Totiltthesteeringwheeltowardyou,pressthefoot
pedaldown,pullthesteeringtowertowardyouto
themostcomfortableposition,andreleasethepedal
(Figure10).T omovethesteeringwheelawayfrom
you,pressthefootpedalandreleaseitwhenthe
steeringwheelreachesthedesiredoperatingposition.
KeySwitch
Thekeyswitch(Figure11)has3positions:OFF,
ON/PREHEAT,andSTART.
g020433
Figure11
1.Liftswitches
(Groundsmaster4700
machineonly)
5.InfoCenter
2.Liftswitch(Groundsmaster
4500and4700machines)
6.Hi-Lospeedcontrol
3.PTOswitch
7.Engine-speedswitch
4.Keyswitch8.Lightswitch
g028454
Figure12
1.Power-pointswitch
2.Cruise-controlswitch
