ServicingtheFuel-Water

Separator

g198661

Figure46

DrainingWaterfromtheFuel/Water

Separator

ServiceInterval:Beforeeachuseordaily—Drain

waterorothercontaminantsfrom

thefuellter/waterseparator

Drainwaterfromthefuel/waterseparatorasshown

in(Figure47).

g225506

Figure47

ReplacingtheFuel-FilterCanister

ServiceInterval:Every400hours—Replacethe

fuel-ltercanister.

Replacethefuel-ltercanisterasshowninFigure48.

g031412

Figure48
