WARNING
Chargingthebatteryproducesgasses
thatcanexplode.
Neversmokenearthebatteryandkeep
sparksandamesawayfrombattery.
5.Whenthebatteryischarged,disconnectthe
chargerfromthepoweroutletandbatteryposts.
6.Installthepositivecable(red)tothepositive(+)
terminalandthenegativecable(black)tothe
negative(-)terminalofthebattery(Figure52).
7.Securethecablestothepostswithboltsand
nuts.
Note:Makesurethatthepositive(+)terminal
isallthewayonthepostandthecableis
positionedsnugtothebattery.Thecablemust
notcontactthebatterycover.
8.CoatbothbatteryconnectionswithGrafo112X
(skin-over)grease,PartNo.505-47,petroleum
jelly,orlightgreasetopreventcorrosion.
9.Slidetherubberbootoverthepositiveterminal.
10.Closetheconsolepanelandsecurethelatch.
LocatingtheFuses
Thefuseblockforthemachineislocatedintheright
storagebox
decal125-4605
Figure53
1.Loosenthelatchforthecoveroftheright
storageboxandraisethecover(Figure54)to
exposethefuseblock(Figure55).
g009985
Figure54
1.Latch2.Rightstoragebox
2.Replacetheopenfuse(s)asneeded(Figure55).
g010255
Figure55
1.Fuses
3.Closethecoveroftherightstorageboxand
securethecoverwiththelatch(Figure54).
