Toro 30934 - Operating the Neutral Locks

Figure9
1.Throttlelever
3.Choke
2.Ignitionswitch
Important:Makesurethatthefuel-shutoff
valveisclosedbeforetransportingorstoringthe
machine,asfuelleakagemayoccur.Beforestoring
themachine,disconnectthewiresfromthespark
plugstopreventthepossibilityofaccidentally
startingtheengine.
OperatingtheNeutralLocks
Alwayssettheneutrallockwhenyoustopthemachine.Set
theparkingbrakeifitisleftunattended.
SettingtheNeutralLock
1.Squeezethedriveleversbackuntilanincreaseinforce
isfelt.
2.Placethumbsontheupperpartofthelocksandmove
themback(
Figure10).
Figure10
1.Handle4.Drivelever
2.Neutrallock
5.Fullspeedforward
3.Neutralposition6.Reverseposition
ReleasingtheNeutralLock
1.Squeezethedriveleversbackuntilanincreaseinforce
isfelt.
2.Placeyourthumbsontheupperpartofthelocksand
movethemforwarduntilthepinsareintheforward
slot(Figure11).
Figure11
1.Handle
4.Pininfullspeedforward
2.Neutrallock5.Handle
3.Drivelever6.Forwardslot
15
