Toro 30934 - Adjusting the Tracking; Adjusting the Spring Anchor Links

Figure43
1.Handle5.Neutralposition
2.Neutrallock6.Drivelever
3.Handle
7.Fullspeedforward
4.Neutrallockslot
8.Controlrod
AdjustingtheTracking
1.Removethemachinefromanyjackstands.
2.Checkthereartirepressure.RefertoCheckingthe
TirePressure.
3.Runthemachineandobservethetrackingonalevel,
smooth,hardsurfacesuchasconcreteorasphalt.
4.Ifthemachinetrackstoonesideortheother,turnthe
quicktrackknob.Turntheknobrighttosteerright
andturntheknoblefttosteerleft(Figure44).
Figure44
1.Quicktrackknob
AdjustingtheSpringAnchor
Links
Formedium-dutyorheavy-dutydriveconditions,suchas
operatingwithasulkyonsteepslopes,ahigherspringforce
mayberequiredonthehydropumpcontrolarmstoprevent
thedrivesystemfromstalling.
1.DisengagethePTOandsettheparkingbrake.
2.Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
