Toro 30934 - Transporting Machines; Side Discharging or Mulching the Grass; Adjusting the Height-Of-Cut

PositionC
Thisisthefullopenposition.Thesuggesteduseforthis
positionisasfollows(Figure18).
•Useintall,densegrassmowingconditions.
•Useinwetconditions.
•Lowerstheenginepowerconsumption.
•Allowsincreasedgroundspeedinheavyconditions.
G012679
Figure18
TransportingMachines
Useaheavy-dutytrailerortrucktotransportthemachine.
Ensurethatthetrailerortruckhasallnecessarylightingand
markingasrequiredbylaw.Pleasecarefullyreadallthesafety
instructions.Knowingthisinformationcouldhelpyou,your
family,petsorbystandersavoidinjury.
Totransportthemachine:
1.Stoptheengine,removethekey,setthebrake,and
closethefuelvalve.
2.Securelyfastenthemachinetothetrailerortruckwith
straps,chains,cable,orropes.
3.Secureatrailertotowingvehiclewithsafetychains.
4.Ifapplicable,connectthetrailerbrakes.
SideDischargingorMulching
theGrass
Thismowerhasahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardtheturf.
DANGER
Withoutthegrassdeector,dischargecover,or
completegrasscatcherassemblymountedin
place,youandothersareexposedtobladecontact
andthrowndebris.Contactwithrotatingmower
blade(s)andthrowndebriswillcauseinjuryor
death.
•Neverremovethegrassdeectorfromthemower
becausethegrassdeectorroutesmaterialdown
towardtheturf.Ifthegrassdeectorisever
damaged,replaceitimmediately.
•Neverputyourhandsorfeetunderthemower.
•Nevertrytocleardischargeareaormower
bladesunlessyoureleasethebailandthepower
takeoff(PTO)isoff.Rotatetheignitionkeyto
Off.Alsoremovethekeyandpullthewireoff
thesparkplug(s).
AdjustingtheHeight-of-Cut
Thismachinehasa26to108mm(1to4-1/4inch)rangefor
theheightofcut.Thiscanbeachievedbyadjustingblade
spacers,rearaxleheight,andfrontcasterspacers.Usethe
Height-of-CutCharttoselectthecombinationofadjustments
required.
AdjustingtheBladeHeight
Adjustthebladesbyusingthe4spacers(6mm)(1/4inch)
onthebladespindlebolts.Thisallowsfora25mm(1inch)
adjustmentrange,in6mm(1/4inch)increments,ofcutting
heightinanyaxleposition.Usethesamenumberofblade
spacersonallbladestoachievealevelcut(2aboveand
2below,1aboveand3below ,etc.).
1.DisengagethePTOandpullthethrottletotheslow
position.
2.Turntheignitionswitchtooff.
3.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.Settheparkingbrake.
4.Holdthebladeboltandremovethenut.Slidethebolt
downthroughthespindle,andchangethespacersas
needed(
Figure19).
19
