CleaningtheSprayerNozzle
ServiceInterval:Aftereachuse
1.Rotatethenozzlecap90°counterclockwiseand
removethecapfromthenozzlebody(Figure
66).
g027398
Figure66
1.Nozzlebody5.Nozzlecap
2.Strainer
6.Atomizer
3.Gasket7.Slot
4.Sprayertip
8.Regulatorcase
2.Removethesprayertip,gasket,andstrainer
fromthenozzlebody(Figure66).
Note:Replaceanywornordamagednozzle
parts.
3.Useasoft-bristlebrushandcleanwatertoclean
thenozzletip,gasket,andstrainer.
4.Assemblethestrainerintothenozzlebody
(Figure66).
5.Assemblethesprayertipandgasketintothe
nozzlecap(Figure66).
6.Installthetip,gasket,andcapontothenozzle
body(Figure66).
Note:Usetheslottorotatetheatomizer(Figure
66)ofthesprayertipforward(in-linewiththe
ow-regulatorcaseofthenozzlebody).
7.Rotatethenozzlecap90°clockwise(Figure66).
8.Repeatsteps1through7forthe2othersprayer
nozzles.
TransportingtheMachine
Machineweight:227kg(500lb)—bothsprayertank
andhopperempty;389kg(857lb)—bothsprayer
tankandhopperfull
CAUTION
Thismachinedoesnothaveturnsignals,
lights,reectivemarkings,oraslow
movingvehicleemblem.Drivingonastreet
orroadwaywithoutsuchequipmentis
dangerousandcanleadtoaccidentscausing
personalinjury.
Donotdrivethemachineonapublicstreet
orroadway.
Note:Refertothechemicalwarningproduct
label(s)beforetransportingthemachineandfollow
alllocal/state/federalrequirementsfortransporting
chemicals.
Note:Makesurethatthespreaderhoppercoverand
thespraywandaresecurebeforetransporting.
LoadingtheMachine
WARNING
Loadingamachineontoatrailerortruck
increasesthepossibilityoftip-overandcould
causeseriousinjuryordeath.
•Useextremecautionwhenoperatinga
machineonaramp.
•Backthemachineuptherampandwalkit
forwarddowntheramp.
•Avoidsuddenaccelerationordeceleration
whiledrivingthemachineonarampas
thiscouldcausealossofcontrolora
tip-oversituation.
•Donotattempttoturnthemachinewhile
ontheramp;youmaylosecontroland
driveofftheside.
•Useonlyasingle,full-widthramp;donot
useindividualrampsforeachsideofthe
machine.
•Ifyoumustuseindividualramps,use
enoughrampstocreateanunbrokenramp
surfacewiderthanthemachine.
Useaheavy-dutytrailerortrucktotransportthe
machine.Ensurethatthetrailerortruckhasall
thenecessarybrakes,lighting,andmarkingas
requiredbylaw.Pleasecarefullyreadallthesafety
instructions.
