SprayingwiththeSprayWand
WARNING
Thespraywandtrapsliquidsunder
highpressure,evenwhenengineisoff.
High-pressurespraydischargecouldcause
seriousinjuryordeath.
•Keepclearofthenozzleanddonotdirect
thesprayorstreamfromthewandat
people,pets,ornon-workareaproperty.
•Donotdirectthesprayatornear
electrical-powercomponentsorsource.
•Donotrepairthespraywand,hoses,seals,
nozzle,orotherwandcomponents;always
replacethem.
•Donotattachthehosesorother
componentstothenozzleattheendofthe
spraywand.
•Donotattempttodisconnectthespray
wandfromthemachinewhilethesprayer
systemispressurized.
•Donotusethespraywandiftriggerlockis
damagedormissing.
•Rotatethespray-wandlocktotheOFF
positionwhenjobiscomplete.
1.Removethewandfromtheholderattheright
sideofthemachine(Figure59).
g305609
Figure59
1.Triggerlock4.Wand
2.Trigger5.Nozzle
3.Wandholder
2.Firmlygripthespraywandandpointitinthe
directionthatyouwillspray.
Note:Thewandmayrecoil;ensurethatyou
holditsecurely.
3.Adjustthepumppressuretothespraywand
performthefollowing:
•Toincreasethepumppressuretothe
wand,rotatethewand-pressurecontrol
counterclockwise(Figure60).
g304905
Figure60
1.Sprayerwandpressurecontrol
•Todecreasepressuretothewand,rotatethe
wand-pressurecontrolclockwisedirection
(Figure60).
•Fullyopenthewand-pressurecontrol,and
usethesprayer-pumpswitchtoadjust
pressuretothewand.
•Toshutoffthepressuretothewand,rotate
thewand-pressurecontrolclockwiseuntilthe
valveforthecontrolisclosed(Figure60).
4.Squeezethetriggertothespray-wandhandle
tobeginspraying;lockthetriggerinplaceif
desired(Figure59).
5.Whennishedspraying,ifyoulockedthetrigger
ofthespray-wand—unlockit,andreleasethe
trigger(Figure59)
6.Rotatethesprayer-wandpressurecontrol
clockwisetotheOFFposition(Figure60).
7.Insertthewandintothewandholder(Figure59).
