SAFETY PRECAUTIONS
1.12
1.12
DECALS
Decal - Control Panel Part No: 994912
Location: Control Panel.
a) Ignition Switch h) Cutters - Off
b) Engine Speed - Slow i) Cutters - Forward
c) Engine Speed - Fast j) Horn
d) Parking Brake - Engage k) Cutters - Lift
e) Parking Brake - Disengage l) Cutters - Hold
f) Weight Transfer - Control m)Cutters - Drop/Float
g) Cutters - Reverse n) Hour Meter
Decal - Inclines Part No: 924857 (1)
Location: Centre Platform.
a) Warning - Travel slowly when turning and on slopes
b) Warning - Maximum slope without ROPS
c) Warning - Seat belt must be worn with a ROPS fitted.
d) Caution
e) Read operators manual
f) Stop engine/Remove ignition key before servicing or
maintenance
g) Beware of flying objects
h) Keep bystanders clear
Decal - Danger Latch Part No: 70-13-077
Location: LH / RH / Centre Arms
a) Caution
b) Stop engine/Remove ignition key before releasing or
operating safety latches
Decal - Diesel Part No: 70-13-078
Location: Fuel Tank
Diesel fuel only
Decal - Transmission Oil Part No: 70-13-071
Location: Oil Filler Bracket mounted behind Fuel Tank.
a) Transmission oil
b) Read and understand the operators manual.
0 - 19°19°+
924857 (1)
a
b
c
de
f
g
h
IMPOR TANT / WICHTIG / BELANGRIJK
BEFORE USE : FILL MACHINE WITH RECOM-
MENDED OILTOCORRECTLEVEL. FAILURE TO
DO SO WILL CAUSE SERIOUS DAMAGEAND IN-
VALIDATE WARRANTY.
AVANT L'UTILISA TION : IL EST IMPERATIF DE
REMPLIR LA TONDEUSE AVEC UNE HUILE
SPECIFIEE AU NIVEAU EXACT POUR NE PAS
L'ENDOMMAGERSERIEUSEMENT ET ANNULER
LAGARANTIE.
VOR DEM GEBRAUCH: F ÜLLEN SIE DIE
MASCHINE MIT EMPFOHLENEM ÖL NACH,BIS
AUF DEN RICHTIGEN ST AND. DIE
NICHTBEACHTUNG DIESER INSTRUKTIONEN
KANN ZU ERNSTHAFTEN SCHADEN FÜHREN
UNDDABEI WIRD DIE GARANTIE UNG ÜLTIG.
VOOR GEBRUIK: VUL MACHINE MET
VORRGESCHREVEN OLIE TOT HET JUISTE
NIVEAU. HET NIET VOLGEN VAN DEZE
INSTRUKTIE LEIDT TOT ERNSTIGE SCHADE EN
VER VAL VAN DE GARANTIE.
a
b
a
b
n
