CUTTERHEAD DRIVE ENGAGEMENT
The cutterhead drive can be engaged only when the operator is
seated correctly, refer - OPERATOR PRESENCE CONTROLS.
Briefly operate the lift control levers to raise the cutterheads,
thereby removing the cutterhead suspension deadweights and wing
units stored energy reaction from the transport latch mechanisms.
Release the cutterhead latches. Operate the cutterhead position
controls to the down / float position and lower all cutterheads to
the ground ready for mowing.
Forward rotation cutterhead drive engagement : Operate the
cutterhead drive switch to the 'Forward' position.
Reverse rotation cutterhead drive engagement : Operate the
cutterhead drive switch to the 'Reverse' position.
To disengage all cutterhead drives : Operate the cutterhead drive
switch to the 'Off' position.
WARNING : PREVENT ACCIDENTS - Refer OPERATOR
PRESENCE CONTROLS for additional information.
1. Forward.
2. Off.
3. Reverse.
