INTRODUCTION
The Toro Reelmaster® 4240-D is a diesel engine powered self propelled machine with hydraulic systems for
ground drive, cutterhead drive, cutterhead lift and steering. The machine operates in four wheel drive at all times,
however, the transmission system can be operated in both ‘work’ and ‘transport’ modes. These modes can be
selected by the operator. In order to optimise machine performance and reduce transmission system wear it is
advisable to operate the machine in the appropriate mode. ‘Work’ signifies cutting operations and ‘Transport’
signifies travelling between work sites. A differential lock function may be selected.
The Toro Reelmaster® 4240-D is a precision built machine designed solely for cutting grass and similar low lying
ground vegetation within the limitations stated in this manual. Use in any other way is considered as contrary
to the intended use. Compliance with and strict adherence to the conditions of operation, service and repair as
specified in this Operators Manual also constitute essential elements of the intended use. The way in which this
machine is operated and maintained will have a profound effect on its performance and reliability.
This manual contains advice on the Toro Reelmaster® 4240-D which should be operated, serviced and repaired only
by persons who are familiar with its particular characteristics and who are acquainted with the relevant safety pro-
cedures.
The safety precautions listed herein and all other generally recognised regulations on safety and all road traffic reg-
ulations must be observed at all times.
Any arbitrary modifications carried out to this machine may relieve The Toro Company of liability for any resulting
damage or injury.
In the pursuit of continuous product development The Toro Company reserves the right to alter specifications with-
out notice.
Cutterhead Variants: The Toro Reelmaster® 4240-D can be fitted with a range of cutterhead configurations
and optional extras:
Optional Extras:
Beacon Kit - Amber flashing warning light.
Lighting Kit - Complies with EC traffic regulations.
R.O.P.S ( Roll Over Protective Structure ) 2 post design.
Cab R.O.P.S. - Full weather protection and roll - over protection.
We recommend the fitting of a Hayter approved R.O.P.S only, to increase operator safety in the event of
a machine rolling over.
Note: with a R.O.P.S. fitted stability angle is decreased to 14 degrees, due to the higher centre of gravity
of the machine
Left and Right: Throughout this manual the terms 'Left' and 'Right' refer to the machine when looking in the
direction of forward travel.
Fixed
Heads
Cutterhead
Number of bladesCylinder diameter
MK3 Cutterhead
200mm
4, 6, 8, 10.
✓
✓
Floating Heads with smooth
or grooved front rollers
254mm
4, 6
✓
INTRODUCTION
1.17
1.17
