HEIZKORPERDECKEL ENTFERNEN ERST WENN DER MOTORKUHLIST.
ONLY REMOVE RADIATOR CAPWHEN ENGINE IS COOL.
VERWIJDERDE RADIATORDOPPAS NADATDE MOTOR ISAFGEKOELD.
IL FAUTTOUJOURSATTENDRELE REFROIDISSEMENTDUMOTEUR
AVANTDERETIRER LE BOUCHONDURADIATEUR.
70-13-073 REV (.0.)
1. Air filter
2. Dust bowl
3. Dust boot
DAILY AND BEFORE USE
Check engine oil level: If the oil level is below the upper mark on the
dipstick, top up with the correct grade of engine oil to the required level,
refer - ENGINE MANUAL.
Check engine radiator coolant level:
WARNING: PREVENT ACCIDENTS - Avoid scalding. DO NOT
remove the radiator filler cap unless the engine is cool. Turn the filler
cap slowly to release system pressure before removing the filler cap
completely.
The coolant level should be 30 - 40mm below the top of the filler neck.
Top up with the correct coolant mixture, refer - ENGINE MANUAL.
IMPORTANT: If you see RED in the Filter Blockage Indicator the air
filter needs replacing.
Cleaning the air cleaner: Remove the air filter and tap it repeatedly with
the palm of the hand to remove dust particles. DO NOT damage the air
filter by hitting it against a hard object. Inspect the air filter for signs of
damage.
IMPORTANT: PREVENT DAMAGE - Always replace a damaged
air filter or damage to the engine will result. NEVER run the engine
without the air filter correctly fitted.
Clean the inside of the cleaner dust bowl with a dry cloth and check that
the dust boot is unobstructed.
Replace the air filter and assemble the dust bowl, with the dust boot
facing below horizontal level.
