Toro 652D User Manual

SPECIFICATIONS
1.23
1.23
Wheel Base:
Working Width:
Cutting Width:
Transport Width:
Overall Length:
Overall Height:
Approx. Working Weight:
WEIGHT AND DIMENSIONS
RECOMMENDED LUBRICANTS AND HYDRAULIC FLUIDS
Grease Points: A good quality medium grease.
Engine: Refer - ENGINE OPERATORS MANUAL.
Hydraulic System:
Should you be in any doubt please contact your Toro dealer. Using incorrect grades will cause
premature wear of hydraulic components and invalidate warranty.
1610 mm.
3640 mm.
3460 mm.
1850 mm at 13mm height of cut.
2930 mm.
1570 mm.
1800 kg less operator, no options fitted.
(The exact weight depends on the cutterhead configuration).
Ambient Temperature Range
0 - 30 C (32 - 86 F)
I S O viscosity grade
46 hydraulic oil.
O
O
15 - 40 C (59 - 104 F)
I S O viscosity grade
68 hydraulic oil.
O
O
O

Toro 652D Specifications

General

Brand	Toro
Model	652D
Category	Lawn Mower
Language	English
