TROUBLE SHOOTING
TROUBLE SHOOTING
When using the following chart it may be found that overhaul of major components or hydraulic
pressure adjustments are necessary. In this case it is recommended that your dealer make these repairs
as he is properly equipped to do this work.
WARNING: PREVENT ACCIDENTS - ALWAYS Apply the parking brake, switch off the engine
and remove the ignition key before attempting to work on the mower.
PROBLEM
Engine will not start with
ignition key.
Flat Battery.
POSSIBLE CAUSE
Transmission neutral interlock
switch not energised.
Parking brake interlock switch
not energised.
Cutterhead drive interlock
switch not energised.
Faulty electrical connection.
Terminal connection
loose or corroded.
Loose or defective
alternator belt.
Defective battery.
Electrical short circuit.
For all other engine problems, refer - ENGINE HANDBOOK.
REMEDY
Remove foot from
forward/reverse travel pedal.
Check setting of transmission
neutral interlock switch.
Operate parking brake lever to
the ‘ON’ position.
Check setting of parking brake
interlock switch.
Move cutterhead drive switch to
the ‘OFF’ position.
Check setting of cutterhead
interlock switch.
Trace and correct fault.
Clean and tighten
terminal connections.
Recharge battery.
Re-tension or replace
drive belt, refer
- ENGINE HANDBOOK.
Recharge battery.
Replace battery.
Trace short circuit and
make good.
