theappropriatenumberof1/2inchspacersonto
thespindleshafttogetthedesiredheightofcut;
thenslidethewasherontotheshaft.
Note:Whenusing25mm(1inch),38mm
(1-1/2inch),oroccasionally51mm(2inch)
heightofcut,movetheskidsandrollertothe
highestholes.
4.Securetheadjustmentwiththetensioningcap.
AdjustingtheSkid(s)
Mounttheskidsinthelowerpositionwhenoperating
ina64mm(2-1/2inch)orhighercuttingheightandin
thehigherpositionwhenoperatinginacuttingheight
lowerthan64mm(2-1/2inches).
Note:Whentheskidsbecomeworn,youcanswitch
theskidstotheoppositesidesofthemower,ipping
themover.Thiswillallowyoutousetheskidslonger
beforereplacingthem.
1.DisengagethePTOandsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,
stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
3.Loosenthescrewatthefrontofeachskid.
(Figure6).
g025671
Figure6
1.Skid
4.Removetheange-headboltsandnutsfrom
eachskid.
5.Moveeachskidtothedesiredpositionand
securethemwiththeange-headboltsandnuts.
Note:Onlyusethetoporcentersetsofholes
toadjusttheskids.Thebottomholesare
usedwhenswitchingsides,atwhichtimethey
becomethetopholesontheothersideofthe
mower.
AdjustingtheRollers
Mounttherollersinthelowerpositionwhenoperating
inheightofcutshigherthan64mm(2-1/2inches)and
inthehigherpositionwhenoperatinginheightofcuts
lowerthan64mm(2-1/2inches).
1.DisengagethePTOandsettheparkingbrake.
2.MovethethrottlelevertotheSlowposition,
stoptheengine,removethekey,andwaitfor
allmovingpartstostopbeforeleavingthe
operatingposition.
3.Raisethefrontofthemachineandsupportiton
jackstands.
4.Removethefastenerssecuringeachrolleron
yourmowerandmovetherollersupordown
asdesired(Figure7).
g004487
Figure7
1.Roller
2.Rollershaft
5.Installthefastenersasillustrated.
LevelingtheMower
Note:Levelingtoolsspecictothiscuttingunitare
availablefromyourAuthorizedT oroDistributor.
LevelingFronttoBack
Cuttingunitpitchisthedifferenceinheightofcut
fromthefrontofthebladeplanetothebackofthe
bladeplane.Tororecommendsabladepitchof
approximately8to11mm(5/16to7/16inch).This
meansthebackofthebladeplaneis8to11mm(5/16
to7/16inch)higherthanthefront.
1.Positionthemachineonalevelsurfaceonthe
shopoor.
2.Setthemowertothedesiredheightofcut,move
thethrottlelevertotheSlowposition,stopthe
engine,settheparkingbrake,andremovethe
ignitionkey.
3.Rotatethecenterbladesothatitpointsstraight
forward.
11

Toro Groundsmaster 360 Series Specifications

General

Cutting Width	72 inches
Deck Type	Side Discharge
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm)
Engine	Yanmar 3-cylinder diesel
