ServicingtheDriveBelts
RefertoFigure21forroutingthedrivebeltsappropriately.
decal121-5498
Figure21
Beltrouting
ServicingtheBushingsin
theCasterArms
Thecasterarmshavebushingspressedintothe
topandbottomofthetubeandaftermanyhours
ofoperation,thebushingswillwear.Tocheckthe
bushings,movethecasterforkbackandforthand
fromsidetoside.Ifthecasterspindleislooseinside
thebushings,thebushingsarewornandmustbe
replaced.
1.Raisethecuttingunitsothatthewheelsareoff
theoor.Blockthecuttingunitsothatitcannot
accidentallyfall.
2.Removethetensioningcap,spacer(s),and
thrustwasherfromthetopofthecasterspindle.
3.Pullthecasterspindleoutofthemountingtube.
Allowthethrustwasherandspacer(s)toremain
onthebottomofthespindle.
4.Insertapinpunchintothetoporbottomofthe
mountingtubeanddrivethebushingoutofthe
tube(Figure22).
g004737
Figure22
1.Casterarmtube
2.Bushings
5.Drivetheotherbushingoutofthetube.
6.Cleantheinsideofthetubestoremoveanydirt.
7.Applygreasetotheinsideandoutsideofthe
newbushings.
8.Usingahammerandaatplate,drivethe
bushingsintothemountingtube.
9.Inspectthecasterspindleforwearandreplace
itifitisdamaged.
10.Pushthecasterspindlethroughthebushings
andthemountingtube.
11.Slidethethrustwasherandthespacer(s)onto
thespindle.
12.Installthetensioningcaponthecasterspindle
toretainallpartsinplace.
18

Toro Groundsmaster 360 Series Specifications

General

Cutting Width	72 inches
Deck Type	Side Discharge
Transmission	Hydrostatic
Turning Radius	0 inches (0 cm)
Engine	Yanmar 3-cylinder diesel
