Groundsmaster 4300--DHydraulic System Page 4 -- 90
Deck Control Manifold
1. Deck control manifold
2. O--ring
3. Diagnostic fitting
4. Dust cap
5. Hydraulic tube
6. O--ring
7. Hydraulic hose
8. O--ring
9. Hydraulic tube
10. Flange head screw (3 used)
11. Hydraulic tube
12. Hydraulic tube
13. Hydraulic tube
Figure 79
FRONT
RIGHT
2
3
6
8
9
10
11
1
5
7
13
12
4
2
3
4
7
6
6
