Groundsmaster 4300--DPage 6 -- 2Chassis
Specifications
Item Description
Front Tire Pressure 12 to 15 PSI (83 to 103 kPa)
(26.5 x 14.0 -- 12, 4 ply, tubeless)
Rear Tire Pressure 12 to 15 PSI (83 to 103 kPa)
(20 x 12.0 -- 10, 4 ply, tubeless)
Wheel Lug Nut Torque 70 to 90 ft--lb (95 to 122 N--m)
General Information
Operator’s Manual
The Operator’s Manual provides information r egarding
the operation, general maintenance and maintenance
intervalsforyourGroundsmaster4300--Dmachine.Re-
fer to that publication for additional information when
servicing the machine.
Special Tools
Order Special Tools from your Toro Distributor.
Wheel Hub Puller
The wheel hub puller allows safe removal of the wheel
hub from the wheel motor shaft.
Toro Part Number: TOR6004
Figure 1
