Groundsmaster 4300--DCutting Decks Page 7 -- 6
Adjustments
CAUTION
Never install or work on the cutting decks or lift
arms with the engine running. Always stop en-
gine and remove key from ignition switch first.
SeetheCuttingDeckOperator’sManualforadjustment
procedures for cutting decks on the Groundsmaster
4300--D.
Blade Stopping Time
The blades of the cutting decks are to come to a com-
plete stop in approximately five (5) seconds after the
PTO is disengaged.
NOTE: Make sure the decks are lowered onto a clean
section of turf or hard surface to avoid dust and debris.
Toverifythisstoppingtime,haveasecondpersonstand
back from the machine at least twenty (20) feet and
watch the blade on one of the cutting decks. Have the
machine operator disengage the PTO and record the
timeittakesforthecuttingdeckbladetocometoacom-
pletestop.Ifthistimeisgreaterthanseven(7)seconds,
the deck control manifold braking valve (RV) may need
adjustment.
