Groundsmaster 4300--DPage 6 -- 4Chassis
Service and Repairs
Wheels
1. Front wheel motor (LH shown)
2. Brake assembly (LH shown)
3. Front wheel hub
4. Lock nut
5. Brake drum
6. Front wheel
7. Lug nut (5 used per wheel)
8. Rear wheel motor (LH shown)
9. Rear wheel hub
10. Rear wheel
11. Lock nut
Figure 2
FRONT
RIGHT
70 to 90 ft--lb
(95 to 122 N--m)
2
3
1
4
5
6
7
8
9
10
11
7
