Groundsmaster 4300--D Cutting DecksPage 7 -- 5
Special Tools
Order special tools from your Toro Distributor.
Rear Roller Bearing and Seal Installation Tools
These tools are used to assemble the cutting deck rear
roller.
Toro Part Numbers:
Inner Seal Tool 115--0852
Bearing/Outer Seal Tool 115--0853
Bearing Installation Washer 107--8133
Figure 1
Inner Seal Tool
Bearing/Outer Seal
Bearing Installation
Washer
Tool
Spindle Plug
The spindle plug can be used to prevent contaminant
entry into the cutting deck spindle assembly when the
hydraulic motor is removed from the spindle.
Toro Part Number: 94--2703
Figure 2
