Toro MB TX 2500S User Manual

g325619
g323276
Figure54
1.Hex2.Fillercap
4.Removethedipstickfromthellerneckand
wipeitwithacleanrag.Insertthedipstickinto
thellerneck;thenremoveitandcheckthe
leveloftheuid.Theuidlevelshouldbeupto
themarkonthedipstick.
g010029
Figure55
1.Dipstick2.Fullmark
5.Ifthelevelislow,addthespeciedhydraulic
uidtoraisetheleveltothefullmark.
6.Installthedipstickandcapontothellerneck.
7.Wipeupanyspilledhydraulicuid.
8.Removethecylinderlockandlowerthehopper.
ChangingtheHydraulicFluidfor
theLiftandSlewSystem
ServiceInterval:Every300hours
1.Parkthemachineonalevelsurface,move
themotion-controlleverstotheNEUTRAL-LOCK
position,engagetheparkingbrake,raisethe
hopper,andinstallthecylinderlock.
2.Shutoffthemachineandremovethekey.Allow
themachinetocoolcompletely.
3.Removethellercapfromthereservoirtank
(Figure54).
CAUTION
Thehydraulicbreather/llercapis
designedtopressurizethereservoirto
34kPa(5psi).
Loosenthecapslowlytoavoidinjury
wheneveraddingoilorworkingonthe
hydraulicsystem.Useawrenchonthe
hexdirectlyunderthecap.
4.Placealargedrainpanunderthettingsatthe
bottomofthereservoirtank.
5.Disconnectahosettingandallowtheuidto
drainintothepan.
6.Whennished,installandtightenthetting.
Note:Disposeoftheuseduidatacertied
recyclingcenter.
7.Fillthereservoirtankwithapproximately5.9L
(200oz)andinstallthellercap.
8.Removethecylinderlock.
9.Starttheengine.Raiseandlowerthehopper3
timestollthecylinderandhoseswithuid.
10.Raisethehopperandinstallthecylinderlock.
11.Shutofftheengine.
12.Add0.73L(25oz)ofhydraulicuidandinstall
thellercap.
Note:TheuidlevelshouldbeattheFullMark
(Figure55).Donotllpastthisline.
13.Removethecylinderlock.
14.Starttheengine.Raiseandlowerthehopper
severaltimestoremoveairfromthesystem.
