Fuses
Theindividualcontrolcircuitsareprotectedbyavarietyoffuses(F-1–F-4)
foundinthefuseblocklocatedonthemachinecontroltowernexttotheengine
(Figure14).
g233941
Figure14
1.Engine3.Fuseblock
2.Fuseblockcover
Theenginewireharnessincludesa30Ain-linefuse(F-5)forchargingcircuit
protection.Theenginefuseislocatednearthestartermotor(Figure15).
g233945
Figure15
1.Enginefuse2.Startermotor
