CHASSIS
3-13
Toro TimeCutter SW/SWX Service Manual
3
FRONT SHROUD - ZERO TURN TRACTOR
5. Install the lock nut and torque to 27-44 ft-lbs (37-
46 Nm).
6. Install the steering wheel cap.
7. Install the traction pedal to the pedal pivot mount,
torque to 5 ft-lbs. (7 Nm).
8. Install the damper to the traction pedal.
Note: It must be placed in the correct position,
torque to 5 ft-lbs. (7 Nm).

Toro TimeCutter SW4200 Specifications

General

Cutting Width	42 inches
Fuel Capacity	3 gallons
Transmission	Hydrostatic
Cutting Height	1.5 to 4.5 inches
Warranty	3-year limited
Type	Zero-turn riding mower
