Toro TimeCutter SW4200 User Manual

HYDROSTATIC DRIVE SYSTEM
5-1
Toro Timecutter SW/SWX Service Manual
5
Chassis Identication
Wide Frame
- All TimeCutter SW 50 and 54 Inch Units
- All TimeCutter SWX 50 Inch Units
Narrow Frame
- All TimeCutter SW 32 and 42 Inch Units
- All TimeCutter SWX 42 Inch Units
Hydrostatic Drive Exploded Views
Wide Frame
(Fig. 041)
Narrow Frame
(Fig. 042)
Fig. 041 PICT-1090
Fig. 042 PICT-1089

Toro TimeCutter SW4200 Specifications

General

Cutting Width	42 inches
Fuel Capacity	3 gallons
Transmission	Hydrostatic
Cutting Height	1.5 to 4.5 inches
Warranty	3-year limited
Type	Zero-turn riding mower
