MOWER DECK
6-11
Toro Timecutter SS/MX/ZS Service Manual
6
6� Attach the front support rod to the deck with the
retaining clip (Fig� 104)�
7� Install the deck belt onto the engine pulley as
outlined in this chapter�
Fig. 104 g.60G014635
A� Front support rod C� Retaining clip
B� Locking nut
A
B
C
Fig. 105 PICT-1053a
