Toro TX 1300 - Controls (Continued); Loader Valve Lock; Joystick Controls; Auxiliary Hydraulics Lock Switch

Loader-ValveLock
Theloader-valvelocksecurestheloader
arm/attachment-tiltleversothatyoucannotpushit
forward.Thishelpstoensurethatnooneaccidentally
lowerstheloaderarmsduringmaintenance.Secure
theloadervalvewiththelock,inadditiontothe
cylinderlocks,anytimeyouneedtoshutoffthe
machinewiththeloaderarmsraised.RefertoUsing
theCylinderLocks(page42).
Tosetthelock,liftitsothatitclearstheholeinthe
controlpanelandswinginfrontoftheloader-arm
lever.Pushitdownintothelockedposition.
g358630
Figure11
1.Loader-valvelock
JoystickControls
g318281
Figure12
1.Attachmentprimary
function(hydraulic
attachmentsonly)
3.Extendandretractthe
loaderarms
2.Attachmentsecondary
function(certain
attachmentsonly)
Note:Theloaderarmsmaynotextendwhenthey
arefullyraisedduetotrappedpressure;lowerthe
armsslightlytorelievepressureandextendthem.
WARNING
Movingthemachinewhiletheloaderarms
areextendedmayaffectthestabilityofthe
machine.
Minimizemachinemovementwhiletheloader
armsareextended.
Auxiliary-HydraulicsLockSwitch
Engagetheforwardorreversehydraulics,thenuse
yourrightfoottopressthelockswitchtocontinuethe
owandfreeyourhandforothercontrols.
g358628
Figure13
1.Auxiliary-hydraulicslockswitch
