7.Ifthelevelislow,addenoughuidtoraiseitto
theproperlevel.
8.Installthellercap.
9.Lowerthebracket.
ReplacingtheHydraulic
Filters
Important:Donotsubstituteanautomotiveoil
lter;otherwise,severehydraulicsystemdamage
mayoccur.
1.Removeanyattachments.
2.Parkthemachineonalevelsurfaceandengage
theparkingbrake.
3.Raisetheloaderarmsandinstallthecylinder
locks.
4.Shutofftheengine,removethekey,andallow
theenginetocool.
5.Removethefrontcover;refertoRemovingthe
FrontCover(page44).
6.Placeadrainpanunderthelterandreplace
thelter.
g031621
Figure101
7.Cleanupanyspilleduid.
8.Starttheengineandletitrunforabout2minutes
topurgeairfromthesystem.
9.Shutofftheengineandcheckforleaks.
10.Checktheuidlevelinthehydraulictank;refer
toCheckingtheHydraulic-FluidLevel(page
62)andadduidtoraisetheleveltomarkon
dipstick.
Important:Donotoverllthetank.
11.Installthefrontcover.
12.Removeandstorethecylinderlocksandlower
theloaderarms.
ChangingtheHydraulic
Fluid
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Placealargedrainpaincapableofholding57
L(15USgallons)underthedrainplugonthe
hydraulictank.
g363374
Figure102
1.Drainplug
4.Removethedrainplugandallowtheoiltodrain
intothepan.
5.Whentheoilisnisheddraining,installand
tightenthedrainplug.
Note:Disposeoftheusedoilatacertied
recyclingcenter.
6.Fillthehydraulictankwithhydraulicuid;refer
toHydraulic-FluidSpecications(page62).
7.Starttheengineandletitrunforafewminutes.
8.Shutofftheengineandremovethekey.
9.Checkthehydraulic-uidlevelandadduidto
llthetankifnecessary;refertoCheckingthe
Hydraulic-FluidLevel(page62).
