Toro TX 1300 - Pre-Maintenance Procedures; Using Cylinder Locks for Safety

Pre-Maintenance
Procedures
UsingtheCylinderLocks
WARNING
Theloaderarmsmaylowerwhenintheraised
position,crushinganyoneunderthem.
Installthecylinderlock(s)beforeperforming
maintenancethatrequiresraisedloaderarms.
InstallingtheCylinderLocks
1.Removetheattachment.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Loosentheknobsecuringthecylinderlockto
theloaderarm.
g359013
Figure57
1.Pin3.Handknob
2.Cylinderlock
5.Slidethecylinderlockoverthelift-cylinderrod.
g267536
Figure58
1.Cylinderlock3.Pin(2)
2.Lift-cylinderrod
6.Repeatstep4and5fortheothersideofthe
machine.
7.Slowlylowertheloaderarmsuntilthecylinder
lockscontactthecylinderbodiesandrodends.
8.Securetheloader-valvelock;referto
Loader-ValveLock(page14).
42
