Toro TX 1300 - Cylinder Locks and Accessing Internal Components; Removing and Storing Cylinder Locks; Opening the Hood; Closing the Hood

RemovingandStoringthe
CylinderLocks
Important:Removethecylinderlocksfromthe
rodsandfullysecuretheminthestorageposition
beforeoperatingthemachine.
1.Starttheengine.
2.Raisetheloaderarmstothefullyraisedposition.
3.Shutofftheengineandremovethekey.
4.Removethepinssecuringthecylinderlocks.
5.Removethecylinderlocksfromthelift-cylinder
rods.
6.Insertthepinsintothelocks.
7.Placethecylinderlocksontheloaderarms,with
thepinringsbeneaththelocks,andsecureeach
lockusingthehandknob.
g359013
Figure59
1.Pin3.Handknob
2.Cylinderlock
8.Lowertheloaderarms.
AccessingInternal
Components
WARNING
Openingorremovingcovers,hoods,and
screenswhiletheengineisrunningcould
allowyoutocontactmovingparts,seriously
injuringyou.
Beforeopeninganyofthecovers,hoods,and
screens,shutofftheengine,removethekey
fromthekeyswitch,andallowtheengineto
cool.
OpeningtheHood
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Unlockthehoodusingthelatchkeyandpress
thebuttontoreleasethelatch.
g362359
Figure60
4.Liftopenthehood
ClosingtheHood
1.Lowerthehood.
2.Pressdownthelatchtosecurethehood.
3.Lockthehoodusingthelatchkey.
