ChangingtheEngineOilandFilter
1.Removeanyattachments.
2.Starttheengineandletitrunfor5minutes.
Note:Thiswarmstheoilsothatitdrainsbetter.
3.Parkthemachineonalevelsurfaceandengage
theparkingbrake.
4.Raisetheloaderarmsandinstallthecylinder
locks.
5.Shutofftheengineandremovethekey.
6.Draintheoilbeneaththeplatform.
CAUTION
Componentswillbehotifthemachine
hasbeenrunning.Ifyoutouchhot
components,youmaybeburned.
Usecaretoavoidtouchinghot
componentswhilechangingtheoil
and/orlter.
g361063
g360882
Figure72
7.Torquethedrainplugto46to56N∙m(34to42
ft-lb).
8.Openthehood.
9.Removetheleftscreen;refertoRemovingthe
SideScreens(page45).
10.Placeashallowpanorragunderthelterto
catchoil.
11.Changetheoillter.
g031261
Figure73
12.Removetheoil-llcapandslowlypour
approximately80%ofthespeciedamountofoil
inthroughthevalvecover.
13.Checktheoillevel.
14.Slowlyaddadditionaloiltobringtheleveltothe
upperholeonthedipstick.
15.Replacethellcap.
16.Installtheleftscreen.
17.Closethehood.
