ChangingtheRadiatorCoolant
ServiceInterval:Every1,000hours/Every2years
(whichevercomesrst)
CAUTION
Iftheenginehasbeenrunning,the
pressurized,hotcoolantcanescapeand
causeburns.
•Donotopentheradiatorcapwhenthe
engineisrunning.
•Allowenginetocoolatleast15minutes
oruntiltheradiatorcapiscoolenoughto
touchwithoutburningyourhand.
•Usearagwhenopeningtheradiatorcap,
andopenthecapslowlytoallowsteamto
escape.
Note:Usea50/50mixofethyleneglycolandwater
forcoolant.
1.Parkthemachineonalevelsurface,shutoffthe
engine,engagetheparkingbrake,andremove
thekeyfromthekeyswitch.
2.Removethellcap(Figure55)andllwith
coolant.
g016859
Figure55
1.Fillcap
2.Radiator-overow-tank
cap
3.Replacethellcapandremovethe
radiator-overow-tankcap(Figure55).
Note:Neverleavebothcapsoffatthesame
time.Thiswilladverselyaffectthellingofthe
tank.
4.Fillwithcoolanttothebottomofthellerneck.
5.Replacetheradiator-overow-tankcapand
cleananyspills.
BrakeMaintenance
InspectingtheBrakes
ServiceInterval:Every100hours
Brakesareacriticalsafetycomponentofthemachine.
Aswithallsafetycomponents,theyshouldbeclosely
inspectedatregularintervalstoensureoptimum
performanceandsafety.Thefollowinginspections
shouldbedoneevery100hours:
•Inspectthebrakeliningforwearordamage.Ifthe
lining(brakepad)thicknessislessthan1.6mm
(1/16inch),thebrakeliningshouldbereplaced.
•Inspectthebackingplateandothercomponents
forsignsofexcessivewearordeformation.If
anydeformationisfound,replacetheappropriate
components.
•Checkthebrake-uidlevel;refertoCheckingthe
Brake-FluidLevel(page20).
Adjustingthe
Parking-BrakeHandle
ServiceInterval:Every200hours
1.Removethehandgripfromtheparking-brake
lever(Figure56).
g029671
Figure56
1.Handgrip
3.Setscrew
2.Brake-adjustmentknob4.Parking-brakelever
2.Loosenthesetscrewsecuringthe
brake-adjustmentknobtotheparking-brake
lever(Figure56).
3.Rotatethebrake-adjustmentknobuntilaforce
of133to156N∙m(30to35ft-lb)isrequiredto
settheparking-brakelever(Figure56).
Note:Ifyourotatedthebrake-adjustmentknob
thefulltraveloftheadjusterandcannotattain
theforceof133to156N∙m(30to35ft-lb)is
47
