Workman e2050/e2065Page 5 – 22Chassis (Rev. B)
Front Hood
1. Hood
2. Flange head screw (6 used)
3. Dash
4. Flange nut (6 used)
5. Fender (LH shown)
6. Bumper
7. Flat washer (2 used)
8. Cap screw (2 used)
9. Flat washer (4 used)
10. Flange head screw (2 used)
11. Flange head screw (2 used)
12. Headlight mount (2 used)
13. Headlight (2 used)
Figure 14
FRONT
RIGHT
6
3
8
9
2
7
2
1
5
4
13
12
11
10
4
9
