Workman e2050/e2065
Page 3 – 42
Electrical System (Rev. B)
Battery Charger
1. Upper case
2. Transformer
3. Lower case
4. SCR assembly
5. Control board
6. Relay
7. Circuit breaker
8. AC cordset
9. DC cordset
10. Ammeter
11. Fuse
12. Diode assembly
Figure 65
3
4
5
8
6
7
9
1
2
10
11
12
For service of the battery charger, see the Lester Electri-
cal Technician Service Guide at the end of this chapter.
