148
model 2000 DeviceNet Module Manual (DN611/DN611A)
Appendix C Definition of Each Request Function Block
C
NUM_WRT2: UINT; (*Number of words to transfer)
DUMMY_W3: BOOL; (*Dummy*)
ADR_WRT3: WORD; (*Extension memory address*)
DAT_WRT3: WORD; (*Transfer source variable*)
NUM_WRT3: UINT; (*Number of words to transfer)
TMR1: TON_100ms (*Acknowledgement wait timer*)
TIME1: DINT; (*Acknowledgement wait time*)
DUMMY_R1: BOOL; (*Dummy*)
ADR_RED1: WORD; (*Extension memory address*)
DAT_RED1: WORD; (*Transfer destination variable*)
NUM_RED1: UINT; (*Number of words to transfer)
COMP_RED1: BOOL; (*Completion*)
DUMMY_R2: BOOL; (*Dummy*)
ADR_RED2: WORD; (*Extension memory address*)
DAT_RED2: ARRAY[0...1] OF WORD; (*Transfer source variable*)
NUM_RED2: UINT; (*Number of words to transfer)
COMP_RED2: BOOL; (*Completion*)
DUMMY_W4: BOOL; (*Dummy*)
ADR_WRT4: WORD; (*Extension memory address*)
DAT_WRT4: WORD; (*Transfer source variable*)
NUM_WRT4: UINT; (*Number of words to transfer)
DUMMY_R3: BOOL; (*Dummy*)
ADR_RED3: WORD; (*Extension memory address*)
DAT_RED3: WORD; (*Transfer source variable*)
NUM_RED3: UINT; (*Number of words to transfer)
COMP_RED3: BOOL; (*Completion*)
ST_STATUS: WORD; (*Station status*)
COMP_RES1: BOOL; (*Compare result*)
COMP_RES2: BOOL; (*Compare result*)
COMP_RES3: BOOL; (*Compare result*)
COMP_RES4: BOOL; (*Compare result*)
TMR2: TON_100ms; (*Error detection timer*)
TIME2: DINT; (*Error detection time*)
END_VAR
